United States Aluminum: Curtain Wall: Series HP3253 High Performance Curtain Wall Systems

Series HP3253 High Performance Curtain Wall Systems

The Series HP3253 High Performance Curtain Wall System for 2" (51 mm) efficient triple-glazed infills, featuring Dual Thermal Break Technology utilizing Poly-Aluminizer. Thermally isolated by a continuous thermal spacer and especially engineered to satisfy the increasing demands for energy conservation, a driven design from the beginning. Two-tone colors can be achieved by specifying different finishes for exterior face members and interior mullions. The system features stick erection with no exposed joint fasteners.

• 2-1/2" (63.5 mm) Face Dimension
• 2" (51 mm) Triple Pane Glazing
• U-Factors from 0.32 to 0.17 Using NFRC100
• Multiple System Depth
• Exterior Glazed
• Injection Molded Water Deflectors
• Three Thermal Break Points
• No Exposed Fasteners
• Vertically Butt Glazed Optional
• Patent No. 7,975,442
