United States Aluminum: Windows: Series 7200 Windows

Series 7200 Window Systems


The Series 7200 Window is dry glazed with tape at the outside and E.P.D.M. elastomeric wedge at the inside. Vent construction is accomplished with tubular members, mitered and reinforced with an extruded aluminum corner key, and hydraulically crimped. Operating hardware options include 90° egress 4 bar hinges, 5 or 3 knuckle butt hinges, roto operators, friction adjusters and stop limit arms. Locking hardware options include cam locking handles, 2 point locking handles and security locks.

• 2" Depth
• C-75 rated
• Available in Fixed, Projected, Inswing and Outswing configurations
• Polyurethane thermal break
• Reinforced corner construction
• Tested for air, water and structural integrity in accordance with ANSI/AAMA 101/ I.S.2-97 or CSAA440-98
• Available in an array of architectural coatings and anodized finishes
