United States Aluminum: Curtain Wall: Series 3252 & 3252SG High Performance Curtain Wall Systems

Series 3252 & 3252SG High Performance Curtain Wall Systems

Series 3252 Curtain Wall System brings ultra high thermal performance to your curtain wall options. Series 3252 is for 1" (25) insulating double pane glazing, and Series 3252SG combines the horizontals mullions of the 3252 with structural silicone glazed vertical mullions. Size Specific U-Factor, SHGC, and VT Matrices are based on the standard Glazed Wall specimen size of 78.75" wide by 78.75" high (2000 mm x 2000 mm). *This represents 90.1% Vision Area / Total Area

• 2-1/2" (63.5 mm) Face Dimension
• 1" (25 mm) Insulating or 1/4" (6 mm) Glazing
• U-Factors from 0.53 to 0.30
• 7" (177.8 mm) Depth
• Exterior Glazed
• Injection Molded Water Deflectors and Closure Plates
• Two Thermal Break Points
• No Exposed Fasteners
• Vertically Butt Glazed Optional
